M400 | SATA | M.2 2280 SSD

SATA

SMART Modular’s M400 SATA M.2 SSDs are designed for demanding enterprise and industrial applications including servers, networking, and storage systems. It supports AES-256 hardware encryption and ATA security features as a Self-Encrypting Drive (SED), and integrates seamlessly into host systems without BIOS or driver modifications.

Built with Single Event Upset (SEU) protection for enhanced data integrity, the M400 helps safeguard against data corruption caused by radiation or voltage fluctuations in harsh environments. It also supports SMART’s NVMsentry™ firmware customization services—offering tailored features to meet specific customer requirements in reliability-critical deployments.

In addition, M400 SATA M.2 2280 SSDs incorporate SMART’s SafeDATA™ power-loss, data-protection technology for graceful handling of power fluctuations and sudden power loss events.

Essentials
M400
eTLC
SATA 3.0 6Gb/s
Performance
Up to 540MB/s
Up to 520MB/s
Up to 79K IOPS
Up to 74K IOPS
240GB
480GB
960GB
1920GB
Reliability
240GB: 471TBW
480GB: 920TBW
960GB: 2114TBW
1920GB: 4237TBW
(JEDEC® Enterprise Workload)
> 2,000,000 hours
1
Environmental
1500G half-sine, 0.5 msec, 1 shock along each axis, X, Y, Z in each direction
20G 80-2000Hz, 1.52mm 20-80Hz, 3 axis
C-temp: 0℃ to +70℃
I-temp: -40℃ to +85℃
-40℃ to +85℃
40℃, Operation: 90% RH, Storage: 93% RH
Physical
80mm
22mm
3.65mm
SRM281920FCM2AJ11920GBC-Temp / SEU Mitigation
SRM281920FIM2AJ11920GBI-Temp / SEU Mitigation
SRM28960GFCM2AJ1960GBC-Temp / SEU Mitigation
SRM28960GFIM2AJ1960GBI-Temp / SEU Mitigation
SRM28480GFCM2AJ1480GBC-Temp / SEU Mitigation
SRM28480GFIM2AJ1480GBI-Temp / SEU Mitigation
SRM28240GFCM2AJ1240GBC-Temp / SEU Mitigation
SRM28240GFIM2AJ1240GBI-Temp / SEU Mitigation
SRM281920F1M2AJ11920GBC-Temp / SafeDATA (pFail) / SEU Mitigation
SRM281920F2M2AJ11920GBI-Temp / SafeDATA (pFail) / SEU Mitigation
SRM28960GF1M2AJ1960GBC-Temp / SafeDATA (pFail) / SEU Mitigation
SRM28960GF2M2AJ1960GBI-Temp / SafeDATA (pFail) / SEU Mitigation
SRM28480GF1M2AJ1480GBC-Temp / SafeDATA (pFail) / SEU Mitigation
SRM28480GF2M2AJ1480GBI-Temp / SafeDATA (pFail) / SEU Mitigation
SRM28240GF1M2AJ1240GBC-Temp / SafeDATA (pFail) / SEU Mitigation
SRM28240GF2M2AJ1240GBI-Temp / SafeDATA (pFail) / SEU Mitigation
